Thermally Broken Alloy Doors

A: The fundamental difference is the thermal barrier. Standard aluminum doors conduct heat directly through the metal frame (U-value 5.0-6.5 W/m²K), while SGL thermal break doors insert a PA66 nylon polyamide strip between interior and exterior aluminum profiles, achieving U-values of 2.0-3.5 W/m²K - a 30-40% reduction in heat transfer. Thermal break doors also deliver superior sound insulation (STC 32-42 dB vs. ~25 dB for standard aluminum), reduced condensation on interior surfaces, and better overall energy efficiency for conditioned spaces. For a deeper understanding, read our article on what is a thermally broken aluminum window - the thermal break principle applies identically to doors.

A: SGL thermal break doors are engineered for a service life of 20-30 years under normal installation and maintenance conditions. To maximize lifespan: (1) Periodically lubricate hinges and locks with silicone-based lubricant (annually recommended); (2) Clean frames with mild soap and water - avoid abrasive cleaners that could damage the powder coating; (3) Check weatherstripping for wear every 3-5 years and replace if compressed; (4) Ensure drainage channels in the frame remain clear. With proper care, many SGL thermal break doors continue performing beyond their 20-year design life.

A: Yes - SGL thermal break doors are specifically designed for humid and coastal environments. The aluminum alloy frame is inherently corrosion-resistant (unlike steel), and our surface finishes provide additional protection: powder coating (≥80μm, salt spray 500-1,000+ hours) or anodizing (Class AA15, ≥15μm). EPDM weatherstripping maintains sealing performance in humidity up to 95% RH without swelling or deterioration. For installations in tropical climates or areas with >80% average humidity, we recommend marine-grade powder coating (1,000+ hour salt spray), SS316 hardware for maximum chloride resistance, and annual inspection of bottom frame drainage channels.

A: U-value (heat transfer coefficient) measures how much heat passes through a door system - lower is better for insulation. SGL's thermally broken alloy doors achieve U-values of 2.0-3.5 W/m²K depending on configuration:

A: 2.5-3.0 W/m²K: PA66 24mm strip + PU foam filling + double glazing (standard)
3.0-3.5 W/m²K: PA66 24mm strip + honeycomb filling + single glass (economy)
For comparison: standard aluminum doors = 5.0-6.5 W/m²K, uPVC doors = 1.8-2.8 W/m²K, timber doors = 2.0-3.0 W/m²K. SGL provides U-value calculation sheets for your specific project configuration upon request.

A: SGL offers the following glazing options:

A: Double glazing / Insulated glass (5+12A+5mm up to 5+27A+5mm) - Standard recommendation. Argon gas filling available for improved U-value.
Laminated glass (5+0.76PVB+5mm or 5+1.52PVB+5mm) - Enhanced security and safety. Improves acoustic insulation by 3-5 dB.
Triple glazing (5+9A+5+9A+5mm) - Maximum thermal performance. U-value as low as 1.8 W/m²K with Low-E coating.
Low-E coated glass - Reflects infrared heat while transmitting visible light. Improves overall door U-value by 10-15%.
All glass options are tempered for safety. Frosted, tinted, and reflective glass available on request.

A: SGL thermal break doors are delivered pre-assembled and pre-hung for straightforward installation: (1) Opening preparation - verify rough opening dimensions, ensure level and plumb, waterproof the opening perimeter; (2) Frame installation - insert the pre-assembled frame, level using shims, fix through pre-drilled frame anchor holes; (3) Sealing - apply polyurethane foam or cement mortar to seal gaps between frame and wall opening; (4) Door hanging - hang the door leaf on pre-installed hinges, adjust for uniform gap (typically 3-5mm around the perimeter); (5) Hardware adjustment - adjust multi-point lock engagement, test handle operation, install threshold; (6) Perimeter sealant - apply silicone sealant to exterior frame-wall interface. SGL provides detailed installation drawings (PDF + DWG), step-by-step installation videos, and remote technical support during installation.

A: SGL thermal break doors are low maintenance. Every 6 months: clean frame surfaces with mild soap and damp cloth, check weatherstripping for compression or damage, lubricate hinges and lock mechanism with silicone spray. Every 12 months: check and clean frame drainage slots (bottom rail), tighten any loose screws on hinges and handles, inspect sealant at frame-wall joints, reapply if cracked. Every 3-5 years: replace EPDM weatherstripping if compressed or perished, check powder coating condition - touch-up kit available for minor scratches. No painting, staining, or rust treatment is required. Unlike wooden doors (stain every 2-3 years) or steel doors (rust spot treatment), SGL thermal break doors maintain their appearance with minimal effort.

A: Yes - SGL thermal break doors are manufactured under ISO 9001:2015 quality management. Thermal performance is tested per EN 10077-2 / GB/T 8484 with U-value calculation reports available for specific configurations. Air/water/wind performance per EN 12207 / EN 12208 / EN 12210 (Class 6-8, Class 5-7A, Class C3-C5 respectively). Acoustic performance per ASTM E413 / ISO 717-1 (STC 32-42 dB). Our U-value range (2.0-3.5 W/m²K) makes SGL thermal break doors eligible for LEED points (EA Credit: Optimize Energy Performance) and BREEAM credits (Ene 01: Reduction of energy use and carbon emissions). We can provide test reports and certification documents from recognized third-party laboratories (SGS, BV, Intertek) upon request.
